Gear Pumps of the Silencer Series
Price-optimized precision pumps for a wide range of applications in the sterilization sector or in beverage technology
Silencer is the introduction model of the series. There are no additional electronics installed in the pump, making it affordable on the one hand, but at the same time also offering genuine application advantages:
It is an excellent choice in applications that require high temperatures, or in others in which fluids are temperature-sensitive. For example, the Silencer is used in sterilization technology or in food technology.
Compared to the introductory model, the difference in the Silencer Smart is the actuation electronics that make it easier to regulate. The Silencer Smart can also be used for manifold design, offering a wide range of installation options. Because of the design, the motor does not need to be encapsulated. This keeps the operating temperature low in the Silencer Smart as well.
The Silencer pumps cover a flow rate bandwidth of 150 milliliters per minute up to 3,500 milliliters per minute.
Application examples
- Sterilization
- Food
- Dialysis
- Analysis
- Diagnostics
- Laser cooling
- Consistent inkjet pressure
Pump specifications of the Silencer Series
The Silencer Series gear pumps are tailor-made to meet your requirements. Look here to view the parameters that allow adjustments to be made:
| Flow Range (ml/min) | 50 to 3000 |
| Maximum continuous Pressure (Bar) | 5 |
| Maximum Intermittent Pressure (Bar) | 6 |
| Self-Priming | Yes |
| Fluid Viscosity Range (cps) (Standard – consult factory for options) | 0.3 to 1000 |
| Motor Types | Standard BLDC / BLDC with integrated motor controller |
| Fluid Temperature (°C) | -20 to +100 |
| Standard Materials (consult factory for options) | 316L or 303 SS, PEEK, EPDM |
Download Datasheets & 3D STEP files
Do you still need more accurate information on our Silencer Series? Here is where you can download the data sheets and 3D STEP files for all of our models.
Datasheets Silencer Series (Format EU/APAC)
Datasheets Silencer Series (Format US)
3D STEP files Silencer Series
| Flow Range (ml/min) | 50 to 3000 |
| Maximum continuous Pressure (Bar) | 5 |
| Maximum Intermittent Pressure (Bar) | 6 |
| Self-Priming | Yes |
| Fluid Viscosity Range (cps) (Standard – consult factory for options) | 0.3 to 1000 |
| Motor Types | Standard BLDC / BLDC with integrated motor controller |
| Fluid Temperature (°C) | -20 to +100 |
| Standard Materials (consult factory for options) | 316L or 303 SS, PEEK, EPDM |
Datasheets Silencer Series (Format EU/APAC)
Datasheets Silencer Series (Format US)
3D STEP files Silencer Series
Your request
Are you interested in our Silencer Series? Just complete the contact form and we will get back to you with a customized quote as soon as possible. Alternatively you can fill out and send an interactive PDF document, which you can download here.
